Problem Solving
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
13-47
Error
Code
Message
Area to Check/
Check Procedure
See Page:
071-105 Paper Jam in Tray 1
Check Tray 1.
Open Cover A and remove paper.
1. Left cover A
2. Tray 1
P. 13-49
P. 13-53
072-102 Paper Jam in Tray 2
Check Tray 2.
Open Cover B and remove paper.
1. One tray module cover B
2. Tray 2
P. 13-51
P. 13-53
072-105 Paper Jam at Cover B
Open Cover B and remove paper.
One tray module cover B P. 13-51
073-102 Paper Jam in Tray 3
Check Tray 3.
Open Cover C and remove paper.
1. Two tray module cover C
2. Tray 3
P. 13-52
P. 13-53
073-104 Paper Jam at Covers B and C
Open Cover B and Cover C, and remove
paper.
1. One tray module cover B
2. Two tray module cover C
P. 13-51
P. 13-52
073-105 Paper Jam at Cover B
Open Cover B and remove paper.
One tray module cover B P. 13-51
074-101
074-102
Paper Jam in Tray 4
Check Tray 4.
Open Cover C and remove paper.
1. Two tray module cover C
2. Tray 4
P. 13-52
P. 13-53
074-104 Paper Jam at Covers B and C
Open Cover B and Cover C, and remove
paper.
1. One tray module cover B
2. Two tray module cover C
P. 13-51
P. 13-52
074-105 Paper Jam at Cover B
Open Cover B and remove paper.
One tray module cover B P. 13-51
075-135 Paper Jam in Tray 5
Remove paper from Tray 5 and remove
paper.
1. Left cover A
2. Tray 5
P. 13-49
P. 13-54
To Next Page
