Product Overview
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
3-12
7 Log In/Out button Press this button to enter or exit System Administration mode (for at
least for 4 seconds) or Account mode. This button lights up when the
machine is in System Administration mode.
8 Numeric keypad Press this button to enter numbers (such as number of copies) or text.
9 Dial Pause button Press this button to insert a pause between numbers when entering a
recipient's number.
10 Machine Status button Press this button to print reports and check the machine information
such as the status of consumables and the machine’s IP address.
11 Energy Saver button Lights up when the machine enters Energy Saver mode to conserve
power when the machine is left idle for a while. You can also press this
button to enter or exit Energy Saver mode.
12 Stop button Press this button to cancel a current job or failed job.
13 ClearAll button Press this button to reset the displayed settings of each feature to
default values or clear the entered numbers. The setting is returned to
the same condition as the machine is powered on.
14 Start button Press this button to start scanning documents or confirm the value of
each setting.
15 Error indicator Blinks if a system error occurs.
This indicator lights up when a problem other than a system error
occurs with the machine, including paper jams and running out of
paper.
16 Data indicator Blinks when the machine is sending or receiving data to or from a
client. This indicator lights up when data is stored in the machine's
memory or when the machine receives faxes waiting to be printed.
17 Speed Dial button Press this button to specify a recipient with entering a Speed Dial
number when sending a fax.
18 C (Clear) button Press this button to delete one numerical value that you have entered.
19 Address Book button Press this button to display the recipients registered for the Address
Book when sending data by fax, e-mail, or network.
20 Back button Press this button to return the display to the previous screen.
21 Collated/Resolution button
(Quick-Button)
Press this button to display the setting screen for the Collated or
Resolution function that lets you change the output method for Copy
feature and the resolution for Scan feature.
This button lights up when this function is available.
22 2 Sided button
(Quick-Button)
Press this button to display the setting screen for the 2 Sided function
that lets you select 2 sided printing for Copy and Scan features.
This button lights up when this function is available.
No. Component Description
