Product Overview
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
3-13
Note Some buttons are not available on some models. If you add certain options, you will be able to
use them. For more information, contact our Customer Support Center.
23 Original Type button
(Quick-Button)
Press this button to display the setting screen for the Original Type
function that lets you change the type of document for Copy, ID Card
Copy, and Scan features.
This button lights up when this function is available.
24 Lighten/Darken button
(Quick-Button)
Press this button to display the setting screen for the Lighten/Darken
function that lets you adjust the brightness for Copy, ID Card Copy,
and Scan features. Also, the Toner Saver setting is available for Copy
feature.
This button lights up when this function is available.
25 Scan button Press this button to use the Scan feature. When the Scan feature is
selected, this button lights up.
For more information, refer to Scan on page 7-1.
26 Fax button Press this button to use the Fax feature. When the Fax feature is
selected, this button lights up.
For more information, refer to Fax on page 6-1.
27 Outline view Used to verify the location indicated in an error message appears on
the display.
28 Paper clip tray Used as a place to store paper clips, staples, etc.
29 One touch panels (Only
available for machines with
the Fax Kit)
Used to specify the recipient when sending a fax. The recipients
registered for one touch buttons 1 to 36 correspond to Speed Dial
numbers 001 to 036.
No. Component Description
