Yaesu FT2DR - Using the DTMF Function; Setting the DTMF Memory

103
Convenient Functions
Using the DTMF Function
DTMF (Dual Tone Multi Frequencies) are the tone signals sent to make telephone calls,
or control repeaters and network links. Up to 10 registers of 16-digit DTMF tone codes
can be stored as telephone numbers to make calls through the public telephone network
using a phone patch.
Setting the DTMF Memory
1
Press and hold the key for over one second.
The transceiver enters Set mode.
2 Touch [SIGNALING].
3 Touch [5 DTMF SELECT].
4 Rotate the DIAL to select the desired channel (1 to 10) to
register the DTMF code, then press the
key.
