Yaesu FT2DR User Manual

144
Customize Menu Settings for Individual Use (Set Mode)
Set Mode: GM Menu Operations
Press and hold the key for over one second to display “SETUP MENU”, then touch
[GM] to set the individual items.
After completing the setup, press to exit from Set mode.
For details on how to set each item, refer to “FT2DR/DE GM Function Instruction Manual”
which is available on Yaesu website.
Set Mode: WIRES-X Menu Operations
Press and hold the key for over one second to display “SETUP MENU”, then touch
[WIRES] to set the individual items.
After completing the setup, press to exit from Set mode.
For details on how to set each item, refer to “FT2DR/DE WIRES-X Instruction Manual”
which is available on Yaesu website.

Yaesu FT2DR Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
GPS	Yes
Waterproof Rating	IPX5
Bluetooth	Yes
Power Output	5 W
Modes	FM, C4FM
Weight	282 g
Operating Voltage	7.4V DC
Battery	7.4 V, 2200 mAh Li-Ion
