169
Appendix
Specifications
y Transmitter
Output Power: 5 W (@ 7.2 V DC or EXT DC)
Modulation Type: F1D, F2D, F3E: Variable Reactance Modulation
F7W: 4 FSK (C4FM)
Spurious Emission: USA/EXP version
At least 60 dB below (@TX Power HI, L3)
At least 50 dB below (@TX Power L2, L1)
European version
At least 60 dB below (@TX Power HI, L3, L2)
At least -36 dBm below (@TX Power L1)
y Receiver
Circuit Type: Double-conversion super heterodyne (NFM / AM)
Direct-conversion (AM / FM Radio)
Intermediate Frequency: 1st: A- Band 47.25 MHz (NFM / AM)
1st: B- Band 46.35 MHz (NFM / AM)
2nd: 450 kHz (NFM / AM)
Sensitivity (for 12dB SINAD):
3
μ V for 10 dB SN (0.5 - 30 MHz, AM)
0.35
μ V TYP for 12 dB SINAD (30 - 54 MHz, NFM)
1
μ V TYP for 12 dB SINAD (54 - 76 (88) MHz, NFM)
1.5
μ V TYP for 12 dB SINAD (76 (88) - 108 MHz, WFM)
1.5
μ V TYP for 10 dB SN (108 - 137 MHz, AM)
0.2
μ V for 12 dB SINAD (137 - 140 MHz, NFM)
0.16
μ V for 12 dB SINAD (140 - 150 MHz, NFM)
0.2
μ V for 12 dB SINAD (150 - 174 MHz, NFM)
1
μ V for 12 dB SINAD (174 - 222 MHz, NFM)
0.5
μ V for 12 dB SINAD (300 - 350 MHz, NFM)
0.2
μ V for 12 dB SINAD (350 - 400 MHz, NFM)
0.18
μ V for 12 dB SINAD (400 - 470 MHz, NFM)
1.5
μ V for 12 dB SINAD (470 - 540 MHz, NFM)
3
μ V TYP for 12 dB SINAD (540 - 800 MHz, NFM)
1.5 μ V TYP for 12 dB SINAD (800 - 999 MHz, NFM, Cellular Blocked)
0.19 μ V TYP for BER 1% (Digital Mode)
(USA Version Cellular Blocked)
Selectivity (−6dB/−60dB): 12 kHz / 35 kHz (NFM/AM)
AF Output:
700 mW (8 Ω for 10 % THD 7.2 V) internal speaker
300 mW (8 Ω for 10 % THD 7.2 V) external speaker
Specifications are subject to change without notice, and are guaranteed within the 144/222 (USA
version)/430 MHz amateur bands only.
