Yamaha F50A - Page 105

62Y3A11
4-6
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Fuel joint 1
2 Fuel filter 1 F50/F50A
3 Fuel filter 1 T50/FT50B, FT50C
4 Fuel pump 1
5Bolt 1 M6
×
25 mm
6 Seal 1
7 Fuel hose 1 Fuel joint-to-fuel filter
8 Clip 3
9Bolt 1 M8
×
14 mm
10 Nut 1
11 Bracket 1
12 Fuel hose 1 Fuel filter-to-fuel pump
13 Fuel hose 2 Fuel pump-to-carburetor
14 Clip 3
15 Bolt 2 M6
×
30 mm
16 O-ring 1
Not reusable
Fuel line
