POWR
Power unit
5-55
62Y3A11
Removing and installing the oil filter
1. Place a rag under the oil filter, and then
remove the filter.
NOTE:
Be sure to clean up any oil spills.
2. Apply a thin coat of the new engine oil to
the O-ring of the new oil filter.
3. Install the oil filter, and then tighten it to
the specified torque.
Disassembling the cylinder body
1. Remove the exhaust cover bolts in the
sequence shown.
Oil filter wrench: YU-38411 / 90890-01426
S62Y5690
S62Y5700
E
Oil filter wrench: YU-38411 / 90890-01426
Oil filter: 18 N·m (1.8 kgf·m, 13 ft·lb)
S62Y5710
