Yamaha F50A - Checking the Propeller Shaft Housing; Checking the Propeller Shaft

LOWR
Lower unit
6-15
62Y3A11
3. Check the Woodruff key
3
and the
groove
a
on the drive shaft for wear.
Replace if necessary.
Checking the propeller shaft housing
1. Clean the propeller shaft housing using a
soft brush and cleaning solvent, and then
check it for cracks. Replace if necessary.
2. Check the teeth and dogs of the reverse
gear for cracks or wear. Replace the
gear if necessary.
3. Check the bearings for pitting or rum-
bling. Replace if necessary.
Checking the propeller shaft
1. Check the propeller shaft for bends or
wear. Replace if necessary.
2. Check the dog clutch and shift plunger
for cracks or wear. Replace if necessary.
S62Y6110
3
S62Y6115
S62Y6120
S62Y6130
