Yamaha F50A - Removing the Water Pump and Propeller Shaft Housing Assembly; Disassembling the Propeller Shaft Housing

LOWR
Lower unit
6-13
62Y3A11
Removing the water pump and
propeller shaft housing assembly
1. Remove the water pump assembly.
2. Remove the propeller shaft housing
assembly by removing the bolts
1
, then
pulling the housing out.
È
For USA and Canada
É
For worldwide
Disassembling the propeller shaft
housing
1. Remove the reverse gear and shim(s).
È
For USA and Canada
É
For worldwide
NOTE:
Install the bearing separator
2
between the
reverse gear and propeller shaft housing
completely, then the other special service
tools.
2. Remove the ball bearing.
Bearing housing puller
2
: YB-06234
Universal puller
3
: YB-06117
Bearing housing puller claw
4
:
90890-06564
Stopper guide plate
5
: 90890-06501
Center bolt
6
: 90890-06504
Slide hammer and adapters
1
: YB-06096
Bearing separator
2
: 90890-06534
Stopper guide plate
3
: 90890-06501
Stopper guide stand
4
: 90890-06538
Bearing puller
5
: 90890-06535
Bearing puller claw 1
6
: 90890-06536
