Yamaha F50A - Checking the Throttle Cable and Shift Cable; Assembling the Tiller Handle

BRKT
Bracket unit
7-15
62Y3A11
Checking the throttle cable and shift
cable
1. Check the operation of the throttle cable
and shift cable.
2. Check the inner wire and outer wire of
both cables for bends or damage, and
the rubber seals for damage. Replace if
necessary.
Assembling the tiller handle
1. Install the throttle shaft
1
and throttle
arm
2
into the frame
3
. Align the mark
a
of the fully closed position of the throt-
tle shaft to the shaft holder. Align the
mark
b
of the fully closed position of the
throttle arm to the indent of the frame.
NOTE:
Make sure that the throttle grip is fully closed
when installing the throttle cable.
