Yamaha F50A - Installing the Drive Shaft; Installing the Lower Unit

62Y3A11
6-28
1
2
3
4
5
6
7
8
I
2. Install the new oil seals to the oil seal
housing as shown.
È
For USA and Canada
É
For worldwide
Installing the drive shaft
1. Install the forward gear, then the drive
shaft assembly, pinion, and pinion nut,
and then tighten the nut to the specified
torque.
È
For USA and Canada
É
For worldwide
Installing the lower unit
1. Set the gearshift to the neutral position at
power unit and lower unit.
Oil seal installer
3
: YB-06168
Driver handle
4
: YB-06071
Needle bearing attachment
5
:
90890-06653
Driver rod L3
6
: 90890-06652
Drive shaft holder
1
: YB-06049
Drive shaft holder 4
2
: 90890-06518
Pinion nut holder
3
: 90890-06505
Socket adapter 1
4
: 90890-06506
Pinion nut: 75 N·m (7.5 kgf·m, 54 ft·lb)
S62Y6850R
2
4
3
É
S62Y6035
N
Drive shaft and lower case (F50/F50A)
