Removing the drive shaft
1. Remove the drive shaft assembly and
pinion, and then pull out the forward
gear.
Disassembling the drive shaft
1. Install the pinion nut
1
, tighten it finger
tight, and then remove the drive shaft
bearing
2
using a press.
È
For USA and Canada
É
For worldwide
CAUTION:
• Do not press the drive shaft threads
a
directly.
• Do not reuse the bearing, always
replace it with a new one.
Disassembling the forward gear
1. Remove the taper roller bearing from the
forward gear using a press.
CAUTION:
Do not reuse the bearing, always replace
it with a new one.
2. Remove the needle bearing from the for-
ward gear.
Drive shaft holder
1
: YB-06049
Drive shaft holder 4
1
: 90890-06518
Pinion nut holder
2
: 90890-06505
Socket adapter 2
3
: 90890-06507
S62Y6850K
1
3
2
Bearing splitter plate
3
: YB-06219
Bearing inner race attachment
4:
90890-06639
Bearing splitter plate 1: YB-06219
Bearing separator 1: 90890-06534
S62Y6740K
1
