Yamaha F50A - Installing the Power Unit

POWR
Power unit
5-67
62Y3A11
12. Install the new gasket and exhaust cover,
and then tighten the bolts to the specified
torques in two stages and in the
sequence shown.
Installing the power unit
1. Install the dowel pins
1
and gasket
2
.
2. Install the power unit
3
by installing the
bolts
4
, then tightening them to the
specified torque.
3. Install the apron
5
.
Exhaust cover bolt:
1st: 6 N·m (0.6 kgf·m, 4.3 ft·lb)
2nd: 12 N·m (1.2 kgf·m, 8.7 ft·lb)
Mounting bolt
4
:
21 N·m (2.1 kgf·m, 15 ft·lb)
