Yamaha F50A - Disassembling the Lower Case

62Y3A11
6-62
1
2
3
4
5
6
7
8
I
È
For USA and Canada
É
For worldwide
CAUTION:
Do not reuse the bearing, always replace
it with a new one.
Disassembling the lower case
1. Remove the taper roller bearing outer
race and shim(s).
È
For USA and Canada
É
For worldwide
NOTE:
Install the claws as shown.
2. Remove the drive shaft bearing outer
race, shim(s), and drive shaft sleeve.
È
For USA and Canada
É
For worldwide
NOTE:
Install the claws as shown.
Slide hammer and adapters
2
: YB-06096
Stopper guide plate
3
: 90890-06501
Stopper guide stand
4
: 90890-06538
Bearing puller
5
: 90890-06535
Bearing puller claw 1
6
: 90890-06536
Slide hammer and adapters
1
: YB-06096
Bearing outer race puller
2
: 90890-06523
Outer race puller claw A
3
: 90890-06532
Slide hammer and adapters
4
: YB-06096
Stopper guide plate
5
: 90890-06501
Stopper guide stand
6
: 90890-06538
Bearing puller
7
: 90890-06535
Bearing puller claw 1
8
: 90890-06536
Drive shaft and lower case (T50/FT50B, FT50C)
