Yamaha F50A - Removing the Propeller Shaft Housing Assembly; Disassembling the Propeller Shaft Housing

LOWR
Lower unit
6-53
62Y3A11
Removing the propeller shaft
housing assembly
1. Straighten the claw washer tabs
a
, and
then remove the ring nut and claw
washer.
2. Pull out the propeller shaft housing
assembly.
È
For USA and Canada
É
For worldwide
Disassembling the propeller shaft
housing
1. Remove the reverse gear and thrust
washer.
È
For USA and Canada
É
For worldwide
Gland nut wrench
1
: YB-34447
Ring nut wrench 3
1
: 90890-06511
Ring nut wrench extension
2
:
90890-06513
Bearing housing puller
3
: YB-06207
Universal puller
4
: YB-06117
Bearing housing puller claw L
5
:
90890-06502
Stopper guide plate
6
: 90890-06501
Center bolt
7
: 90890-06504
Slide hammer and adapters
1
: YB-06096
Bearing separator
2
: 90890-06534
Stopper guide plate
3
: 90890-06501
Stopper guide stand
4
: 90890-06538
Bearing puller
5
: 90890-06535
Bearing puller claw 1
6
: 90890-06536
