Yamaha F50A - Checking the Pinion and Forward Gear; Checking the Bearings; Checking the Drive Shaft; Checking the Lower Case

LOWR
Lower unit
6-63
62Y3A11
3. Remove the needle bearing.
Checking the pinion and forward
gear
1. Check the teeth of the pinion, and the
teeth and dogs of the forward gear for
cracks or wear. Replace if necessary.
Checking the bearings
1. Check the bearings for pitting or rum-
bling. Replace if necessary.
Checking the drive shaft
1. Check the drive shaft for bends or wear.
Replace if necessary.
Checking the lower case
1. Check the skeg and torpedo for cracks or
damage. Replace if necessary.
Assembling the lower case
1. Install the needle bearing into the lower
case to the specified depth.
Bearing housing needle bearing remover
9
:
YB-06153
Needle bearing attachment
9
:
90890-06611
Driver handle
0
: YB-06071
Driver rod L3
0
: 90890-06652
S62Y6780
S62Y6785
