62Y3A11
5-48
1
2
3
4
5
6
7
8
I
3. Compress the valve spring, and then
install the valve cotter
8
using a thin
screwdriver with a small amount of
grease applied to it.
4. Lightly tap the spring retainer with a plas-
tic hammer to set the valve cotter
securely.
Installing the camshaft
1. Install the new oil seal
1
.
È
For USA and Canada
É
For worldwide
2. Install the camshaft
2
in the direction
shown, then the retaining bolt
3
.
Drive shaft needle bearing depth stop:
YB-34473
Bearing outer race attachment:
90890-06626
S62Y5630
1
Cylinder head
