Yamaha F50A - Tilt Cylinder and Trim Cylinder

62Y3A11
7-56
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Power trim and tilt motor 1
2 Tilt cylinder end screw 1 90 9.0 65
3Bolt 3 M5
×
20 mm 4 0.4 2.9
4 O-ring 1
Not reusable
5 Joint 1
6 O-ring 1
Not reusable
7Ball 6
8 O-ring 1
Not reusable
9 Free piston 1
10 Circlip 1
11 Trim cylinder base 1
12 Spring 2
13 Plate 1
14 Circlip 1
15 Tilt cylinder assembly 1
16 O-ring 1
Not reusable
17 Reservoir cap 1 6.5 0.65 4.7
18 Anode 1
19 Bolt 2 M6
×
25 mm
Tilt cylinder and trim cylinder
