Yamaha F50A - Swivel Bracket and Steering Arm

62Y3A11
7-48
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Steering arm 1
2 Washer 1
3 Bushing 1
4 O-ring 2
Not reusable
5 Bushing 2
6 Swivel bracket 1
7 Bushing 1
8 Port tilt stop lever 1
9 Circlip 1
10 Steering yoke 1
11 Bushing 1
12 Bushing 1
13 Tilt stop lever joint 1
14 Spring holder 1
15 Bolt 1 M6
×
10 mm
16 Spring 1
17 Bushing 1
18 Pin 2
19 Bushing 1
20 Starboard tilt stop lever 1
Swivel bracket and steering arm
