62Y3A11
7-14
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Tiller handle 1
2 Cotter pin 1
Not reusable
3 Friction adjusting knob 1
4Grommet 1
5 Plastic tie 1
6 Cable clamp 1
7Stay 1
8Bolt 1 M6
×
14 mm
9 Throttle cable 1 Short
10 Clip 1
11 Throttle arm 1
12 Throttle arm shaft 1
13 Shift cable 1 Long
14 Shift cable bracket 1
15 Bolt 1 M6
×
14 mm
16 Clip 1
17 Frame 1
18 Screw 2 M5
×
14 mm
19 Bolt 1 M6
×
14 mm
20 Spring housing 1
21 Spring 1
22 Actuator 1
23 Roller 1
24 Bushing 1
25 Shift arm 1
26 Bolt 2 M6
×
30 mm
27 Throttle shaft 1
28 Friction piece 1
29 Nut 1
Tiller handle (F50/F50A, T50/FT50B)
