No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Propeller shaft assembly 1
2 Propeller shaft housing
assembly
1
3 Spacer 1
4Grommet 1
5Bolt 4 M8
×
20 mm
6 Water pump housing 1
7 Insert plate cartridge 1
8Impeller 1
9 O-ring 1
Not reusable
10 Outer plate cartridge 1
11 Gasket 1
Not reusable
12 Dowel pin 2
13 Woodruff key 1
14 Slider 1
15 Spring 1
16 Cross pin 1
17 Dog clutch 1
18 Spring 1
19 Propeller shaft 1
20 Shift plunger 1
21 Washer 1
22 Bolt 2 M8
×
25 mm
23 Reverse gear 1
24 Reverse gear shim — As required
25 Ball bearing 1
26 O-ring 1
Not reusable
27 O-ring 2
Not reusable
28 Propeller shaft housing 1
29 Needle bearing 1
30 Oil seal 2
Not reusable
Water pump and propeller shaft housing (F50/F50A)
