Yamaha F50A - Page 107

62Y3A11
4-8
1
2
3
4
5
6
7
8
I
È
F50/F50A
É
T50/FT50B, FT50C
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Fuel filter cup 1
2 O-ring 1
Not reusable
3 Fuel filter element 1
4 Body 1
5Float 1
6 Screw 4 M5
×
35 mm
7 Cover 1
8 Fuel pump body 2 1
9 Fuel pump body 1 1
10 Nut 4
11 Plunger 1
12 Spring 1
13 Spring 1
14 Pin 1
15 Diaphragm 1
16 Screw 2 M3
×
6 mm
17 Valve 2
18 Nut 2
19 Seal 1
Not reusable
20 Gasket 1
Not reusable
Fuel filter and fuel pump
