62Y3A11
5-2
1
2
3
4
5
6
7
8
I
Check the wiring harnesses for
continuity.
Replace the wiring harnesses.
Check that the combustion
camber is filled with engine oil
or gasoline.
Check the starter motor.
Check operation of the starter
motor pinion.
Remove all spark plugs, and
then the engine.
Listen for the operation sound
of the starter relay.
Check the power unit.
Is there conti-
nuity?
Can the oper-
ation sound
be heard?
Does the pin-
ion rotate?
Replace the starter
relay.
Does the
engine
crank?
Yes
Yes
Yes
Yes
No
No
No
No
Troubleshooting
To Next Page
