Yamaha F50A - Page 141

62Y3A11
5-14
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Flywheel magnet 1
2 Stator coil 1
3 Cover 1
4Grommet 2
5 Nut 1 160 16 116
6 Washer 1
7Bolt 3 M6
×
25 mm
8 Lighting coil coupler 1
9 Charge coil coupler 1
10 Stator base 1
11 Pulser coil coupler 1
12 Screw 4 M6
×
24 mm 4 0.4 2.9
13 Dowel pin 2
14 Woodruff key 1
15 Cover 1
16 Screw 3 M6
×
35 mm 3 0.3 2.2
Power unit
