Yamaha F50A - Page 143

62Y3A11
5-16
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Throttle cable 1
2 Shift cable 1 F50/F50A, T50/FT50B
3 Shift cable 1 FT50C
4 Fuel pump 1
5 Fuel filter assembly 1 F50/F50A
6 Fuel filter assembly 1 T50/FT50B, FT50C
7 Carburetor assembly 1
8Bolt 3 M6
×
20 mm
9Plate 1
10 Clip 1
11 Clip 1
12 Grommet 1
13 Holder 1 F50/F50A, T50/FT50B
14 Holder 1 FT50C
15 Bolt 2
16 O-ring 1
Not reusable
17 Clip 2
18 Fuel hose 2 Fuel pump-to-carburetor
19 Bolt 1
20 Clip 1
21 Fuel hose 1 Fuel filter-to-fuel joint
22 Bolt 8
23 O-ring 4
Not reusable
24 Dowel pin 2
25 Clip 1
26 Blowby hose 1
27 Prime Start coupler 1
28 Bolt 2 M6
×
30 mm
29 Collar 2
30 Throttle link rod 1
Power unit
