Yamaha F50A - Page 145

62Y3A11
5-18
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Power trim and tilt relay 1 EHT/ET models
2Bolt 1 M8
×
16 mm 9 0.9 6.5
3 Negative battery lead 1
4 Wiring harness extension 1
5Grommet 1
6 Nut 1 7 0.7 5.1
7 Spring washer 1
8 Positive battery lead 1
9 PTT relay positive lead 1 EHT/ET models
10 Fuse holder lead 1
11 Clip 1
12 Warning indicator coupler 1 EHD/EHT models
13 Trailer switch coupler 1 EHT/ET models
14 Plastic tie 1
Not reusable
15 Pilot water hose 1
16 Bolt 2 M6
×
20 mm
17 Neutral switch 1 Tiller handle models
18 Plate 1 Remote control models
19 Neutral switch lead 2 Tiller handle models
20 Ground lead 3
21 Bolt 1 M6
×
12 mm
22 PTT relay lead 2 EHT/ET models
23 Nut 2 EHT/ET models
24 Spring washer 2 EHT/ET models
25 PTT motor lead 2 EHT/ET models
Green, blue
26 Bolt 2 M6
×
20 mm
EHT/ET models
Power unit
