No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1Bracket 1
2 Starter motor 1
3 Spark plug cap 4
4 Ignition coil 2
5 Wiring harness 1
6 Thermoswitch 1
7 Holder 1
8Bolt 1 M6
×
12 mm
9 Ground lead 3
10 Bolt 1 M6
×
12 mm
11 Oil pressure switch 1 9 0.9 6.5
12 Oil pressure switch lead 1
13 Screw 1 2 0.2 1.4
14 Ignition coil lead 2
15 Bolt 4 M6
×
30 mm 7 0.7 5.1
16 Thermoswitch lead 2
17 Rectifier Regulator coupler 1
18 CDI unit coupler 1
19 Bolt 2 M8
×
25 mm 30 3.0 22
20 Bolt 3 M8
×
35 mm
21 Nut 1
22 Spring washer 1
23 Starter motor lead 1
24 Spring washer 1
25 Nut 1 7 0.7 5.1
26 Bolt 1 M8
×
45 mm 30 3.0 22
Power unit
