Yamaha F50A - Page 157

62Y3A11
5-30
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Timing belt 1
2 Drive sprocket 1
3 Driven sprocket 1
4 Bolt 1 8 0.8 5.8
5Bolt 1 M8
×
20 mm 25 2.5 18
6 Tensioner 1
7Spring 1
8 Nut 1 140 14 101
9 Retaining plate 2
10 Woodruff key 1
11 Bolt 1 M10
×
40 mm 38 3.8 28
12 Washer 1
13 Bolt 2 M6
×
20 mm
14 Blowby hose 1
15 Clip 1
16 Dowel pin 1
Timing belt and sprockets
