LOWR
Lower unit
6-19
62Y3A11
5. Install the O-ring
5
, pump housing
assembly
4
, and dowel pins
6
into the
lower case, tighten the bolts
7
, and then
install the grommet
8
and spacer
9
.
NOTE:
• When installing the pump housing, apply
grease to the inside of the housing, and
then turn the drive shaft clockwise while
pushing down the pump housing.
• Align the spacer projection
a
with the hole
b
in the pump housing.
S62Y6200J
A
a
b
9
8
7
4
6
5
6
