62Y3A11
6-30
1
2
3
4
5
6
7
8
I
WARNING
Do not hold the propeller with your hands
when loosening or tightening it. Be sure
to remove the battery leads from the bat-
teries and the engine shut-off switch. Put
a block of wood between the cavitation
plate and propeller to keep the propeller
from turning.
NOTE:
If the grooves in the propeller nut
4
do not
align with the cotter pin hole, tighten the nut
until they are aligned.
Propeller nut
4
:
35 N·m (3.5 kgf·m, 25 ft·lb)
Drive shaft and lower case (F50/F50A)
To Next Page
