Yamaha F50A - Page 241

62Y3A11
6-42
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Lower unit 1
2 Plastic tie 1
Not reusable
3Hose 1
4 Check screw 1 7 0.7 5.1
5 Gasket 2
Not reusable
6 Dowel pin 2
7 Bolt 4 M10
×
40 mm 40 4.0 29
8 Drain screw 1 7 0.7 5.1
9Grommet 1
10 Bolt 1 M10
×
45 mm, : 12 mm
11 Bolt 1 M8
×
60 mm
12 Thrust washer 1
13 Propeller 1
14 Washer 1
15 Washer 1
16 Cotter pin 1
Not reusable
17 Propeller nut 1 35 3.5 25
18 Trim tab 1
Lower unit (T50/FT50B, FT50C)
