Yamaha F50A - Page 245

62Y3A11
6-46
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Shift rod assembly 1
2 Oil seal 1
Not reusable
3 Oil seal housing 1
4 O-ring 1
Not reusable
5 Circlip 1
6 Shift rod 1
7 O-ring 1
Not reusable
8Bolt 2 M6
×
16 mm
9 Woodruff key 1
10 Bolt 2 M8
×
55 mm
11 Bolt 2 M8
×
45 mm
12 Water pump housing 1
13 Grommet 1
14 Gasket 1
Not reusable
15 Insert plate cartridge 1
16 Impeller 1
17 Outer plate cartridge 1
18 Gasket 1
Not reusable
19 Dowel pin 2
20 Oil seal housing assembly 1
21 Gasket 1
Not reusable
22 Oil seal housing 1
23 O-ring 1
Not reusable
24 Oil seal 2
Not reusable
Water pump and shift rod (T50/FT50B, FT50C)
