Yamaha F50A - Page 285

62Y3A11
7-6
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Tiller handle assembly 1
2 Friction plate 1
3 Tiller handle wiring
harness
1
4 Tiller handle wiring
harness
1 Models applicable for
tachometer, trim meter or
warning buzzer
5Grommet 1
6 Clip 1
7 Throttle cable 1
8Plate 1
9Bolt 3 M6
×
20 mm
10 Bolt 1 M8
×
16 mm 9 0.9 6.5
11 Negative battery lead 1
12 Cable guide 1
13 Grommet 1
14 Nut 1 7 0.7 5.1
15 Washer 1
16 Positive battery lead 1
17 Connector 1
18 Clip 1
19 Shift cable 1
20 Plastic tie 2
21 Cover 1
22 Screw 3 M6
×
35 mm
23 Trailer switch coupler 1
24 PTT switch coupler 1 Models with trailer switch
25 Bolt 1 M6
×
35 mm
26 Screw 1 M6
×
25 mm
27 Collar 1
28 Clamp 1
29 Nut 2 37 3.7 27
30 Bolt 2 M6
×
16 mm
Tiller handle (F50/F50A, T50/FT50B)
