Yamaha F50A - Page 301

62Y3A11
7-22
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1Bracket 1
2Bolt 2 M6
×
16 mm
3Bolt 2 M6
×
16 mm
4 Shift arm guide 1
5Nut 1
6 Washer 1
7 Washer 1
8 Bushing 1
9 Tiller handle bracket 1
10 Nut 1
11 Bushing 1
12 Engine stop switch 1
13 Bolt 1 M6
×
20 mm
14 Engine start switch
housing
1
15 Screw 1 M6
×
12 mm
16 Connector 1 Black
17 Connector 1 White
18 Engine start switch 1
19 Screw 1 M6
×
30 mm
20 Screw 1 M6
×
25 mm
21 Collar 1
22 Ball 1
23 Spring 1
24 Shift arm 1
25 Washer 1
26 Shift grip 1
27 Clip 1
28 Shift rod 1
Tiller handle (FT50C)
