62Y3A11
7-26
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Shift rod assembly 1
2 Bottom cowling 1
3Bolt 1
4Spring 1
5Ball 1
6 Shift rod bracket 1
7 Cotter pin 1
Not reusable
8 Washer 1
9 Bushing 1
10 Bushing 1
11 Shift rod 1
12 Grommet 1
13 Rubber seal 4
14 Bolt 4 M6
×
30 mm
15 Grommet 4
16 Screw 1 M6
×
14 mm
EHD/EHT models
17 Warning indicator 1 EHD/EHT models
18 Grommet 1 EHD/EHT models
19 Collar 4
20 Pilot water outlet 1
21 Plastic tie 2
Not reusable
22 Collar 2
23 Grommet 2
24 Bushing 2
25 Joint 1
26 Cowling lock lever 1
27 Pin 1
28 Cotter pin 2
Not reusable
29 Pin 1
30 Cotter pin 1
Not reusable
Bottom cowling
