62Y3A11
7-28
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
31 Bolt 2 Models with trailer switch
32 Bracket 1 Models with trailer switch
33 Trailer switch 1 Models with trailer switch
34 PTT motor lead 1 EHT/ET models
35 Trim sensor coupler 1 EHT/ET models
36 Screw 1 M6
×
24 mm
EHT/ET models
37 Grommet 1
38 Flushing hose 1 Models with flushing
device
39 Adapter 1 Models with flushing
device
40 Bolt 1 M6
×
20 mm
Models with flushing
device
41 Rubber seal 1
42 Hose 1
Bottom cowling
To Next Page
