Yamaha F50A - Page 311

62Y3A11
7-32
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Upper case assembly 1
2 Nut 2 24 2.4 17
3 Nut 2 42 4.2 30
4 Washer 2
5Bolt 3 M8
×
30 mm
6 Upper mount 1
7Plate 1
8Bolt 2 M8
×
175 mm
9Cap 2
10 Bolt 2 M12
×
160 mm
11 Grommet 2
12 Ground lead 1
13 Screw 2
14 Mount cover 2
15 Bolt 4 M8
×
25 mm
16 Mount housing 2
17 Spring 4
18 Washer 2
19 Rubber washer 2
20 Lower mount 2
21 Washer 2
22 Grease nipple 1
Upper case
