Yamaha F50A - Page 315

62Y3A11
7-36
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Oil seal 1
Not reusable
2 Exhaust guide 1
3Grommet 1
4 Gasket 1
Not reusable
5 Dowel pin 2
6 Bolt 10 M6
×
25 mm
7Oil pan 1
8 Gasket 1
9 Exhaust manifold 1
10 Bolt 3 M6
×
50 mm
11 Gasket 1
Not reusable
12 Bolt 6 M6
×
25 mm
13 Muffler 1
14 Gasket 1
Not reusable
15 Pipe 1
16 Rubber seal 1
Not reusable
17 Gasket 1
Not reusable
18 Relief valve housing 1
19 Bolt 2 M6
×
25 mm
20 Bolt 2 M6
×
16 mm
21 Bolt 1 M6
×
25 mm
22 Oil strainer 1
23 Relief valve 1
24 Spring 1
25 Cotter pin 1
Not reusable
Upper case
