Yamaha F50A - Page 331

62Y3A11
7-52
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1 Power trim and tilt 1 EHT/ET models
2 Hydro tilt 1 EHD/ED models
3 Plastic tie 3
Not reusable
4 PTT motor lead 2
5 Washer 2
6Bolt 2 M8
×
16 mm
7 Circlip 1 EHT/ET models
8 Shaft 1 EHT/ET models
9 Bushing 2 EHT/ET models
10 Collar 1 EHT/ET models
11 Tilt pin 1
12 Collar 1
13 Collar 1
14 Shaft 1
15 Bushing 2 EHD/ED models
16 Circlip 2 EHD/ED models
17 Shaft 1 EHD/ED models
18 Collar 1 EHD/ED models
Power trim and tilt unit
