Yamaha F50A - Page 337

62Y3A11
7-58
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1Tilt ram 1
2 Dust seal 1
Not reusable
3 Backup ring 1
4 O-ring 1
Not reusable
5 Tilt cylinder end screw 1
6 O-ring 1
Not reusable
7 Backup ring 1
8 O-ring 1
Not reusable
9 Trim cylinder end screw 1 80 8.0 58
10 O-ring 1
Not reusable
11 O-ring 1
Not reusable
12 Trim piston 1
13 O-ring 1
Not reusable
14 Trim cylinder 1
15 O-ring 1
Not reusable
16 Backup ring 1
17 Ball 1
18 Tilt piston 1
19 Ball 4
20 Absorber valve pin 4
21 Spring 4
22 Pin 4
23 Pin 2
24 Washer 1
25 Bolt 1 M12
×
45 mm 61 6.1 44
Trim cylinder
