Yamaha F50A - Page 339

62Y3A11
7-60
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1Bolt 2 M5
×
8 mm 5 0.5 3.6
2 Relief valve bracket 1
3Bolt 3 M6
×
40 mm 7 0.7 5.1
4 Valve lock screw 1
5 Up-relief spring 1
6 Valve support pin 1
7 O-ring 1
Not reusable
8Ball 1
9 Down-relief spring 1
10 Valve support pin 1
11 Relief valve seal 1
12 Filter 1
13 O-ring 2
Not reusable
14 Spacer 2
15 Filter 2
16 O-ring 1
Not reusable
17 Manual release plug 1
18 Circlip 1
Gear pump
