Yamaha F50A - Page 341

62Y3A11
7-62
1
2
3
4
5
6
7
8
I
No. Part name Q’ty Remarks
Tightening torques
Stage N·mkgf·mft·lb
1Bolt 2 M5
×
20 mm 5 0.5 3.6
2 Washer 2
3 Gear pump bracket 1
4 O-ring 2
Not reusable
5 Spacer 2
6Spring 2
7 Valve pin 2
8Ball 2
9 Manual release spring 1
10 Ball 2
11 Gear pump cover 1
12 Spring 2
13 Shuttle piston 1
14 O-ring 1
Not reusable
15 Valve seal 2
16 Circlip 2
17 Pin 2
18 Drive gear 1
19 Shaft 1
20 Driven gear 1
21 Ball 2
22 Shuttle piston 1
23 Valve plate 1
24 Plate 1
25 Gear pump housing 1
Gear pump
