Yamaha F50A - Page 347

62Y3A11
7-68
1
2
3
4
5
6
7
8
I
4. Install the backup ring
5
and O-rings
6
and
7
into the trim cylinder end screw
8
.
5. Install the trim cylinder end screw onto
the tilt ram.
6. Install O-rings
9
and
0
onto the trim pis-
ton
A
, and then install the trim piston to
the trim cylinder
B
.
7. Install the backup ring
C
and O-ring
D
into the tilt piston
E
.
8. Install balls
F
and
G
, absorber valve pin
H
, spring
I
, pins
J
and
K
, and washer
L
into the tilt piston.
9. Hold the tilt ram end in a vise using alu-
minum plates on both sides.
10. Install the tilt piston to the tilt ram by
installing the bolt, then tightening it to the
specified torque.
11. Install the trim cylinder onto the tilt ram.
12. Hold the trim cylinder
M
in a vise using
aluminum plates
a
on both sides.
NOTE:
Place the trim cylinder in the vise horizon-
tally.
S62Y7740
Tilt piston: 61 N·m (6.1 kgf·m, 44 ft·lb)
Gear pump
