7. Remove the reservoir cap
1
, and then
check the fluid level in the reservoir.
8. If necessary, add sufficient fluid of the
recommended type to the correct level.
NOTE:
The fluid level should be at the brim of the
filler hole.
9. Install the reservoir cap.
NOTE:
Repeat this procedure until the fluid remains
at the correct level.
Recommended power trim and tilt fluid:
ATF Dexron
II
Gear pump
