Lower unit (T50/FT50B, FT50C)
Check screw — 70.75.1
Lower unit bolt M10 40 4.0 29
Drain screw — 70.75.1
Propeller nut — 35 3.5 25
Ring nut — 105 10.5 76
Water inlet cover screw — 50.53.6
Pinion nut M22 95 9.5 69
Bracket unit
Tiller handle assembly nut (F50/F50A) — 37 3.7 27
Engine shut-off switch nut (F50/F50A) — 40.42.9
Tiller handle bracket nut (F50/F50A) — 38 3.8 27
Main switch nut (F50/F50A) — 50.53.7
Friction wing nut (FT50C) — 13 1.3 9.4
Tiller handle assembly nut (FT50C) — 37 3.7 27
Throttle cable (short) locknut (FT50C) — 37 3.7 27
Upper mount nut — 24 2.4 17
Lower mount nut — 42 4.2 30
Trim sensor screw M6 2 0.2 1.4
Clamp bracket self-locking nut — 23 2.3 17
Power trim and tilt
Tilt cylinder end screw — 90 9.0 65
PTT motor bolt M5 4 0.4 2.9
Reservoir cap — 6.5 0.65 4.7
Trim cylinder end screw — 80 8.0 58
Tilt piston bolt M12 61 6.1 44
Relief valve bracket bolt M5 5.3 0.53 3.8
Gear pump assembly bolt M6 6.5 0.65 4.7
Gear pump bracket bolt M5 5.3 0.53 3.8
Electrical unit
Pulser coil screw — 40.42.9
Starter motor nut — 90.96.5
Part to be tightened Thread size
Tightening torques
N·mkgf·mft·lb
Tightening torques
