Yamaha F50A - Page 81

62Y3A11
3-6
1
2
3
4
5
6
7
8
I
2. Place a drain pan under the drain hole,
and then remove the drain bolt
2
and let
the oil drain completely.
3. Place a rag under the oil filter, and then
remove the filter.
NOTE:
Be sure to clean up any oil spills.
4. Apply a thin coat of the new engine oil to
the O-ring of the new oil filter.
5. Install the oil filter, and then tighten it to
the specified torque.
6. Install the drain bolt, and then tighten it to
the specified torque.
7. Fill the specified engine oil into the oil
filler hole.
Oil filter wrench: YU-38411 / 90890-01426
S62Y3080
2
S62Y3100
Oil filter wrench: YU-38411 / 90890-01426
Oil filter: 18 N·m (1.8 kgf·m, 13 ft·lb)
Drain bolt: 18 N·m (1.8 kgf·m, 13 ft·lb)
Recommended engine oil:
4-stroke motor oil
API: SE, SF, SG, or SH
SAE: 10W-30, 10W-40, or 20W-40
S62Y3110
E
S62Y3115
Fuel system / Power unit
