CAUTION:
• Apply force in the direction of the
arrows shown, to prevent the flywheel
holder from slipping off easily.
• To prevent damage to the engine or
tools, screw in the flywheel puller set
bolts evenly and completely so that the
flywheel puller plate is parallel to the fly-
wheel magnet.
NOTE:
Apply force to the crankshaft end until the fly-
wheel magnet comes off the tapered portion
of the crankshaft.
3. Disconnect the stator couplers
3
, and
then remove the stator
4
.
4. Disconnect the pulser coil coupler
5
,
and then remove the stator base
6
with
both collars
7
.
5. Remove the blowby hose bolts
8
and
tensioner
9
, then the timing belt
0
from
the driven sprocket side.
Flywheel magnet holder
1
: YB-06139
Flywheel holder
1
: 90890-06522
Universal puller
2
: YB-06117
Flywheel puller
2
: 90890-06521
