oPE02 Error Occurs when Lowering the Motor Rated Current Setting
Cause Possible Solutions
The motor rated current and the motor no-load current
settings in the drive are incorrect.
The user is trying to set the motor rated current in E2-01 to a value lower than the no-load current
set in E2-03.
• Make
sure that value set in E2-01 is higher than E2-03. Setting E2-01 < E2-03 will trigger an
oPE02 error.
• If it is necessary to set E2-01 lower than E2-03, first lower the value set to E2-03, then change
the setting in E2-01 as needed.
n
Motor Stalls During Acceleration or With Large Loads
Cause Possible Solutions
Load is too heavy.
Take the following steps to resolve the problem:
•
Reduce the load.
• Increase the acceleration time.
• Increase motor capacity.
• Although the drive has a Stall Prevention function and a Torque Compensation Limit function,
accelerating too quickly or trying to drive an excessively large load can exceed the capabilities
of the motor.
n
Motor Will Not Accelerate or the Acceleration Time is Too Long
Cause Possible Solutions
Frequency reference is too low.
• Check the maximum output frequency (E1-04).
•
Increase E1-04 if it is set too low.
Check U1-01 for proper frequency reference.
Check if a frequency reference signal switch has been set to one of the multi-function input terminals.
Check for low gain level set to terminal A1 (H3-03).
Load is too heavy.
• Reduce the load so that the output current remains within the motor-rated current.
•
In extruder and mixer applications, the load will sometimes increase as the temperature drops.
Check if the mechanical brake is fully releasing as it should.
Acceleration time has been set
too long.
Check if the acceleration time parameters have been set too long (C1-01, -03).
Motor characteristics and drive
parameter settings are
incompatible
with one another in
V/f Control.
• Set the correct V/f pattern so that it matches the characteristics of the motor being used.
• Check the motor data and adjust V/f pattern settings.
Incorrect frequency reference
setting.
• Check the multi-function analog input settings.
•
Ensure the analog input value is set to the right value (U1-13).
The Stall Prevention level during
acceleration and deceleration set
too low.
• Check the Stall Prevention level during acceleration (L3-02).
•
If L3-02 is set too low, acceleration will take a fair amount of time.
• Increase L3-02.
The Stall Prevention level during
run has been set too low.
• Check the Stall Prevention level during run (L3-06).
•
If L3-06 is set too low, speed will drop as the drive outputs torque.
• Increase the setting value.
n
Drive Frequency Reference Differs from the Controller Frequency Reference Command
Cause Possible Solutions
The analog input frequency gain and bias are set to
incorrect values.
Check the frequency reference terminal input gain level assigned to terminal A1 (parameter
H3-03).
n
Poor Speed Control Accuracy
Cause Possible Solutions
Slip compensation function disabled or set up
incorrectly.
Adjust the slip compensation gain (C3-01).
