YASKAWA J1000 Technical Manual

n
Removing
the Protective Covers on a NEMA Type 1 Design (Using the NEMA Type 1 Kit Option
for the NEMA Type 1 Rating)
1.
Loosen the screw on the front cover to remove the front cover.
Figure 8.11 Remove the Front Cover
2.
Loosen
the screw on the terminal cover (Figure 8.12, B) to remove the terminal cover and expose the conduit bracket
(Figure 8.12, A).
A
B
Figure 8.12 Remove the Terminal Cover
3.
Loosen two screws attaching the conduit bracket (Figure 8.13, A) to remove.
A
Figure 8.13 Remove the Conduit Bracket
n
Reattaching the Protective Covers
Pass power wiring and control signal wiring through the exit holes on the bottom of the conduit bracket of the drive. Place
power
wiring and control signal wiring in separate conduits. Properly connect all wiring after installing the drive and connecting
other devices. Reattach all protective covers when wiring is complete.
8.4 Installing Peripheral Devices
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
175
8
Peripheral Devices & Options
http://nicontrols.com

YASKAWA J1000 Specifications

General

Series	J1000
Voltage Class	200V, 400V
Frequency	50/60 Hz
Enclosure Rating	IP20
Enclosure Type	Open type
Voltage	200-240V, 380-480V
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault, Short Circuit
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Humidity	5-95% (non-condensing)
Enclosure	IP20
Input Voltage	200-240V, 380-480V
